INFINITY 26 GAS WATER HEATER
Never Run Out of Hot Water
This is where RINNAI INFINITY is Used
-
Residential Bathrooms
-
Club Houses
-
Bungalows
-
Jacuzzis
-
Bathtubs
-
Multiple Bathrooms
Description.
Infinity 26
- > Unparalleled in performance, the Rinnai Infinity 26 is the favourite electronic continuous flow hot water system in most countries suiting 1-5 bathroom homes.
- > Enjoy superior comfort with reduced running costs, as no energy is consumed by the unit until you turn a tap on. With an impressive 6 star energy rating, the Rinnai 26 the most energy efficient 26L continuous flow hot water system on the market.
- > Designed to withstand tough conditions, the slimline unit not only saves you precious outdoor space but offers precise temperature control display, enhanced safety monitor and puretemp™ stability control.
- > Customise and complete your Infinity 26 system with our comprehensive range of hot water controllers to enhance your experience
Technical data
>
Specifications
|
Dimensions (mm) : Height |
571 |
|
Dimensions (mm) : Width |
356 |
|
Dimensions (mm) : Depth |
202 |
|
Colours |
White |
|
Factory Default Temperature (Celsius) |
50 or 60 |
|
Water Pressure (kPa) : Minimum |
200 |
|
Water Pressure (kPa) : Maximum |
1000 |
|
Gas Rate Max : NG |
199 |
|
Flow Rate 25 Degrees C/Max : l/min |
26 |
|
Star Rating |
6.0* Equivalent |
|
Connection Sizes Gas/Hot/Cold (mm) |
20/20/20 |
|
Status Monitor |
Yes |
|
Dimensions (mm) : Height Inc Brackets |
571 |
|
Dimensions (mm) : Hot Water Outlet (From Wall) |
87 |
|
Dimensions (mm) : Hot Water Outlet (Left from Centre) |
105 |
|
Dimensions (mm) : Cold Water Inlet (From Wall) |
68 |
|
Dimensions (mm) : Cold Water Inlet (Right from Centre) |
10 |
|
Dimensions (mm) : Gas Connection (From Wall) |
77 |
|
Dimensions (mm) : Gas Connection (Right from Centre) |
83 |
|
Dimensions (mm) : Gas Connection Length (From Base) |
40 |
|
Dimensions (mm) : Cold Connection Length (From Base) |
50 |
|
Weight (kg) |
15.5 |
